SNP500 – Aquatherm

SNAPPITZ INSULATION OD SINGLE LAYER DIMENSIONAL DATA FOR AQUATHERM

				IPS OD		IPS OD		IPS OD		IPS OD
SKU Code	Snappitz Pipe Size	d(in)	Aquatherm Pipe Size	½"	Snappitz AQ-OD	1"	Snappitz AQ-OD"	1½"	Snappitz AQ-OD"	2"	Snappitz AQ-OD"
AQ-0012	½"	0.79	20mm	1.9	1.94	2.875	2.94	4.0	4.0	5.0	5.0
AQ-0034	¾"	0.98	25mm	2.160	2.190	2.875	2.94	4.0	4.0	5.0	5.0
AQ-0100	1"	1.26	32mm	2.160	2.190	3.5	3.652	4.5	4.63	5.563	5.63
AQ-0114	1¼"	1.57	40mm	2.875	2.94	3.5	3.625	5.0	5.0	5.563	5.63
AQ-0112	1½"	1.97	50mm	2.875	2.94	4.0	4.0	5.0	5.0	5.563	5.63
AQ-0200	2"	2.48	63mm	3.5	3.625	4.5	4.63	5.563	5.625	5.625	6.69
AQ-0212	2½"	2.95	75mm	4.0	4.0	5.0	5.0	6.625	6.6875	7.625	7.75
AQ-3000	3"	3.54	90mm	4.5	4.63	5.563	5.63	6.625	6.6875	7.625	7.75
AQ-0312	3½"	4.33	110mm	5.0	5.6	6.625	6.69	7.625	7.75	8.625	8.63
AQ-0400	4"	4.92	125mm	6.625	6.69	7.625	7.75	8.625	8.63	9.625	9.6875
AQ-0600	6"	6.3	160mm	7.625	7.75	8.625	8.63	9.625	9.6875	10.625	10.6875
AQ-0800	8"	7.87	200mm	9.625	9.6875	10.625	10.6875	11.625	11.6875	12.625	12.6875
AQ-01000	10"		250mm			12.625	12.6875	13.95	13.95	14.95	14.95
AQ-01200	12"		315mm			14.95	14.95	15.95	15.95	16.95	16.95
AQ-01400	14"		355mm			15.95	15.95	16.95	16.95	17.95	17.95
AQ-01600	16"		400mm			17.95	17.95	18.95	18.95	19.95	19.95
AQ-01800	18"		450mm			19.95	19.95	20.95	20.95	21.95	21.95
AQ-02000	20"		500mm			21.95	21.95	22.95	22.95	23.95	23.95
AQ-02400	AQ-2400	24"		630mm			23.95	23.95	24.95	24.95	25.95	25.95
